AirWall New 60MD (6,000 CFM) Dust Collection Ventilation System (ECB Module)

Call for Quote - (231) 894-0333

The AirWall® is a self contained cartridge filter unit with a small footprint that does not require ductwork and operates with lower horsepower fans than traditional models. The AirWall® unit automatically cleans the cartridge filters utilizing compressed air. It comes in various standard sizes or can be built to your specifications.

SKU: JD-1442 Categories: AirWall Environmental Modules, Dust Collectors, New Dust Collection Equipment Tags: Downflow Work Station, DWS, ECB, Environmental Control Booth

Share Via Email or Social Media:

Description

Description

AirWall New 60MD Dust Collection Ventilation System (ECB Module)

Specifications:

6,000 CFM @ 1.7:1 Air-To-Cloth Ratio from (15) Cellulose Cartridge Filters
Total Media 3,600 Sq.Ft.
Automatic Reverse Pulse Filter Cleaning System from shop compressed air
Structural Steel Frame with 18 Ga. Galvanized Sheet Metal Skin
5Hp TEFC UL/CSA Approved Motor/Blower unit
80″ Width, 48″ Depth, 60″ Height 2,080 Lbs.
Starter, Dwyer® Pulse Timer & Gage included
Removes 99.9% of Airborne Contaminants
